Example: Trust Atlas¶

The Trust Atlas is a read-only explorer over the recognition graph. It shows sovereigns, trust relationships, treaty scope, and — when supplied — TrustEvidence records overlaid on the edges they describe. It derives everything from signed protocol data and exposes no write paths.

Two consumption modes:

Live operator console (/atlas) — rendered from the NA’s live recognition graph on every request.
Static snapshot (atlas build) — a self-contained atlas.html + atlas.json you can publish anywhere, with optional TrustEvidence overlay.

        flowchart LR
    graph["/recognition-graph"]
    atlas_json["/atlas.json"]
    atlas_page["/atlas"]
    build["atlas build"]
    static["atlas.html / atlas.json"]
    evidence["TrustEvidence files"]
    operator["Operator"]
    external["External viewer"]

    graph --> atlas_json
    graph --> atlas_page
    graph --> build
    evidence --> build
    build --> static
    operator --> atlas_page
    external --> static

What This Proves¶

Any party with the recognition graph export and a set of TrustEvidence files can produce a verifiable, self-contained Atlas snapshot without running an NA.
Active, expiring-soon, and revoked edges are distinct and labelled.
Treaty scope (allowed roles) is visible per relationship.
Verified TrustEvidence records are displayed against the edges they describe; unverifiable records are shown as unverified, never silently accepted.
The graph_digest in atlas.json and atlas.html ties the snapshot to the exact graph state it was built from.

Prerequisites¶

A running Network Authority with at least one recognition treaty issued. For the static build, a recognition graph JSON export (from /recognition-graph). For the evidence overlay, TrustEvidence files produced by genesis-mesh trust evidence (see Example: Trust Evidence).

Part 1: Live operator console¶

The /atlas page is available on any running NA at http://<na>/atlas. It requires no extra configuration and refreshes from the live graph on each request. The top navigation bar links to it directly next to Connectome.

The companion /atlas.json endpoint returns a machine-readable summary:

curl -s https://na.example.org/atlas.json | python -m json.tool

Expected shape:

{
  "sovereigns": [{"sovereign_id": "sovereign-a"}, {"sovereign_id": "sovereign-b"}],
  "recognition_edges": [ ... ],
  "active_treaty_count": 2,
  "revoked_trust_material_count": 0,
  "graph_digest": "<sha256-hex>"
}

The graph_digest is the SHA-256 hex of the canonical graph export. It is deterministic: the same graph state always produces the same digest.

Part 2: Static snapshot (`atlas build`)¶

1. Export the recognition graph¶

curl -s https://na-a.example.org/recognition-graph > fleet-graph.json

2. Build the static Atlas¶

genesis-mesh atlas build \
  --graph fleet-graph.json \
  --output ./atlas-snapshot/

This writes:

atlas-snapshot/atlas.json — machine-readable snapshot with graph digest
atlas-snapshot/atlas.html — self-contained HTML page (no server, no CSS dependencies, viewable offline)

3. Open the static Atlas¶

# Open in a browser
start atlas-snapshot/atlas.html       # Windows
open atlas-snapshot/atlas.html        # macOS
xdg-open atlas-snapshot/atlas.html   # Linux

Or publish to GitHub Pages, object storage, or any static host.

Part 3: TrustEvidence overlay¶

The Atlas can overlay verified TrustEvidence records produced by genesis-mesh trust evidence. Each record is signature-checked against the supplied public key(s) and its graph_digest is compared against the snapshot’s own graph digest.

1. Issue TrustEvidence records (Sovereign A)¶

genesis-mesh trust evidence \
  --graph fleet-graph.json \
  --from sovereign-a \
  --to sovereign-b \
  --role role:service:maintainer \
  --issuer-sovereign sovereign-a \
  --signing-key .genesis-mesh/keys/na.key \
  --key-id na-2026-q1 \
  --output evidence/a-b.json

Repeat for each relationship you want to overlay.

2. Build the Atlas with evidence overlay¶

genesis-mesh atlas build \
  --graph fleet-graph.json \
  --output ./atlas-snapshot/ \
  --evidence ./evidence/ \
  --public-key <sovereign-a-public-key-base64>

Evidence in ./evidence/ is read, verified, and overlaid. The summary output:

Graph: 2 sovereign(s), 2 edge(s) — digest a3f1b2c8d9e0...
  atlas.json: atlas-snapshot/atlas.json
  atlas.html: atlas-snapshot/atlas.html
  evidence: 1/1 verified, 0 unreadable

Exit code 0 when all evidence verifies. Exit code 1 if any record fails verification or cannot be parsed — the Atlas is still written but the caller knows something is wrong.

3. Failure cases¶

Wrong public key supplied — evidence appears as unverified in the HTML; exit code 1.

Evidence file is not a TrustEvidence JSON — skipped and counted in unverifiable_count; exit code 1.

Graph has changed since evidence was issued — evidence digest does not match current graph digest; marked unverified.

What Atlas is not¶

Atlas is not a trust authority. It describes the graph; it does not rate or rank participants.
Atlas cannot mutate treaties, feeds, or decisions. All surfaces are read-only.
Atlas does not replace the Connectome. The Connectome is the detailed operator view of edges, revocation blast radius, and trust-path explanations. Atlas is the broader relational view — who can do what, under what scope — with evidence overlay.
