Example: Formal PeerRiskSignal Verification (Tamarin)

The PeerRiskSignal algorithm (v0.37) has been validated empirically: tests confirm that the EWMA formula and anomaly detection produce expected outputs for known inputs. Empirical tests cannot prove the absence of attacks — they show the algorithm works on inputs we chose, not on all possible adversarial inputs.

Two specific attack questions require formal treatment:

  1. Threshold manipulation: can an adversary craft outcome sequences that keep |Δ - μ| < 3σ indefinitely, preventing anomaly detection while still degrading a sovereign’s trust standing?

  2. Cascade amplification: can a single adversarial counterparty trigger simultaneous anomaly blocks at two or more independently-observing sovereigns? If yes, this is a denial-of-service vector against the mesh’s authorization capacity.

v0.48 extends the Tamarin Prover models introduced in v0.31 to cover the PeerRiskSignal state machine. Three security lemmas are proven.

Scope constraint: Tamarin proves properties of the protocol specification, not the Python implementation. An implementation bug that correctly implements the protocol is not caught. The Tamarin models in ops/tamarin/risk_signal/peer_risk_signal.spthy are executable specifications, not part of the Python test suite.

Formal risk signal verification demo

The three lemmas

Lemma 1 — signal_bounded

The signal value is always in the lattice {low, mid, high} (abstracting [0.0, 1.0]) after any sequence of InitSignal, UpdateSignal, and DecaySignal rule applications.

This proves the ge=0.0, le=1.0 invariant on PeerRiskSignal.signal at the protocol level, independent of Python’s floating-point clamping.

Lemma 2 — anomaly_detection_responsive

Whenever a SuddenDrop action is recorded for (S, C), there exists a subsequent AnomalyDetected action for (S, C).

This proves that an adversary causing a sudden large negative delta cannot permanently suppress anomaly detection — the EmitAnomaly rule must eventually fire. The lemma holds for all possible interleavings of UpdateSignal and DecaySignal.

Lemma 3 — no_single_source_cascade

If AnomalyDetected(S1, C) and AnomalyDetected(S2, C) are both observed for distinct sovereigns S1 ≠ S2, then each sovereign must have independently observed a SuddenDrop(Sn, C) before its own anomaly fired.

This proves that cascade amplification requires genuine divergent behaviour visible to each independent observer. A single adversary cannot “tunnel” one event into simultaneous anomaly alarms at multiple sovereigns.

Running the proofs

With Tamarin Prover installed:

# Prove all three lemmas
tamarin-prover --prove ops/tamarin/risk_signal/peer_risk_signal.spthy

# Prove a single lemma
tamarin-prover --prove=signal_bounded ops/tamarin/risk_signal/peer_risk_signal.spthy
tamarin-prover --prove=anomaly_detection_responsive ops/tamarin/risk_signal/peer_risk_signal.spthy
tamarin-prover --prove=no_single_source_cascade ops/tamarin/risk_signal/peer_risk_signal.spthy

The Python test wrappers in genesis_mesh/tests/test_risk_signal_tamarin.py invoke tamarin-prover automatically and are marked @pytest.mark.skipif so they are skipped when tamarin-prover is not installed.

Executable property tests (no Tamarin required)

genesis_mesh/tests/test_risk_signal_formal.py exercises the same boundary conditions at the Python level without requiring the prover:

  • Property 1 — bounded: 7 tests over all combinations of outcomes, random sequences, and boundary initials (0.0 and 1.0).

  • Property 2 — responsive: anomaly fires after sustained success followed by failures; alternating adversarial patterns cannot suppress it.

  • Property 3 — cascade isolation: two independent sovereigns maintain independent signals; anomaly at one does not propagate to the other.

These tests run in the standard pytest suite.

What is NOT proved

  • Implementation fidelity: the Python update_risk_signal() correctly implements the EWMA formula, but Tamarin proves the abstract protocol, not the Python code. A Python bug that correctly realises the protocol (e.g. numerical precision drift) is not caught.

  • Timing attacks: the model abstracts time as a non-deterministic decay operator. Real-time attacks exploiting the exponential decay formula’s continuous nature are not in scope.

  • Cross-sovereign collusion: Lemma 3 covers single-adversary cascade. If two sovereigns collude to construct a shared signal history, that is outside the threat model.

Model simplifications

The Tamarin model uses a three-point lattice {low, mid, high} instead of the continuous [0.0, 1.0] range. This is sufficient to prove the structural properties (boundedness, detection responsiveness, cascade isolation) while keeping the model decidable. A fully arithmetic Tamarin model would require the diff or xor built-ins and is left for future work.
