Formal Verification + Interop Bridges¶

Formal verification and credential bridge demo

Formal Verification (Tamarin Prover)¶

The GenesisMesh trust protocol is formally verified using Tamarin Prover — a symbolic security analysis tool for multi-party protocols.

Model location¶

ops/tamarin/gm_protocol.spthy

The model captures the core protocol pipeline (v0.26–v0.30):

Agreement (Offer/Counter/Accept)
  → Authorization (BoundaryDecision)
    → Execution (ExecutionEvidence)

Five security lemmas¶

Lemma	Property
`authorization_requires_agreement`	Every BoundaryDecision is causally downstream of an AgreementRecord
`execution_requires_authorization`	Every ExecutionEvidence record is causally downstream of a BoundaryDecision
`agreement_has_two_signers`	An agreement requires both offerer and responder to have acted
`delegation_requires_agreement`	No delegation can exist without a root agreement
`execution_traceability`	Each execution has a unique, non-repeatable evidence_id

Running the proofs¶

# Install Tamarin Prover (https://tamarin-prover.com/)
tamarin-prover --prove ops/tamarin/gm_protocol.spthy

All five lemmas verify in Tamarin’s symbolic model. In CI, the Python test harness runs the proofs automatically:

python -m pytest genesis_mesh/tests/test_tamarin_proofs.py -v

The test skips gracefully when tamarin-prover is not installed.

Interop Bridges¶

GenesisMesh records can be converted to common external formats for integration with heterogeneous ecosystems.

SPIFFE Bridge (`trust interop to-spiffe`)¶

Maps an AgreementRecord to a SPIFFE SVID-like JSON. The GM signatures are preserved as extensions.

genesis-mesh trust interop to-spiffe \
    --agreement agreement.json \
    --output svid.json

{
  "spiffe_id": "spiffe://org-a/3b7e9f12-...",
  "trust_domain": "org-a",
  "capabilities": ["transactions.read"],
  "gm_signatures": [...]
}

W3C Verifiable Credential Bridge (`trust interop to-vc`)¶

Maps an AgreementRecord or TrustEvidence to a W3C VC.

# From an AgreementRecord
genesis-mesh trust interop to-vc \
    --agreement agreement.json \
    --output agreement-vc.json

# From TrustEvidence
genesis-mesh trust interop to-vc \
    --evidence trust-evidence.json \
    --output evidence-vc.json

The VC follows the https://www.w3.org/2018/credentials/v1 context. GM signatures are in proof._gm_signatures.

JOSE/JWT Bridge (`trust interop to-jwt`)¶

Encodes a BoundaryDecision as a signed EdDSA JWT (RFC 8037).

genesis-mesh trust interop to-jwt \
    --decision decision.json \
    --signing-key keys/bridge.key --key-id bridge-2026 \
    --output decision.jwt

Standard JWT claims are populated from the decision:

jti → decision_id
iss → operator_sovereign_id
exp → decision_valid_until
gm:authorized, gm:agreement_id, gm:gate_results in the gm: namespace

The JWT can be verified by any JOSE library that supports alg: EdDSA with crv: Ed25519 (RFC 8037 OKP key type).

Bridge invariants¶

Bridges are lossy by design: not all GM fields map to external formats.
All output carries _gm_bridge_source so consumers know provenance.
Reverse mappings (svid_to_agreement_fields, vc_to_trust_evidence_fields) return best-effort dicts, never re-signed GM records.
JWT verification requires the original Ed25519 public key.
