Example: Attenuable Delegation Chain¶

An Attenuable Delegation Chain lets a party holding an AgreementRecord sub-delegate a strict subset of its rights to a third party — and so on through multiple hops — while every hop is independently signed and verifiable.

The core invariant is:

Delegated capabilities ⊆ parent capabilities, at every hop. Delegated validity window ⊆ parent validity window, at every hop. Any hop that widens scope or extends validity makes the entire chain unverifiable.

What a chain proves¶

Identity at every hop: each DelegatedAgreementRecord requires two independent Ed25519 signatures — delegator and delegate. Neither can produce it alone.
Strict attenuation: each hop’s delegated_terms is verifiably a subset of the parent’s terms. The chain cannot expand scope.
Root anchoring: the chain root is always an AgreementRecord from trust agree. Trust root remains the treaty graph.
Forensic reconstructibility: the chain is a linked list of signed records. Any party can walk root → terminal and verify each hop independently.
Parent-terms binding: each record’s parent_terms_digest is the SHA-256 of the parent’s agreed_terms canonical JSON. If the parent’s terms change, the digest breaks and the delegation requires renewal.

Architecture¶

AgreementRecord  (org-a ↔ bank-a)        — root, dual-signed
      ↓
DelegatedAgreementRecord  (org-a → agent-x)  — hop 1, dual-signed
      ↓
DelegatedAgreementRecord  (agent-x → agent-y) — hop 2, dual-signed

Prerequisites¶

A dual-signed AgreementRecord (from trust agree).
Each delegating party’s Ed25519 operator key.
Each receiving party’s recognition-graph export.

Flow: Org-A delegates to Agent X¶

1. Org-A creates the delegation (half-signed)¶

genesis-mesh trust delegate create \
    --agreement agreement.json \
    --from org-a \
    --to agent-x \
    --capability transactions.read \
    --valid-until 2026-12-01T00:00:00Z \
    --graph org-a-graph.json \
    --signing-key org-a.key --key-id org-a-2026 \
    --output delegation-half.json

Org-A sends delegation-half.json to Agent X.

2. Agent X cosigns (dual-signed)¶

genesis-mesh trust delegate cosign \
    --delegation delegation-half.json \
    --graph agent-x-graph.json \
    --signing-key agent-x.key --key-id agent-x-2026 \
    --output delegation.json

delegation.json is now dual-signed. Either party can verify it.

3. Verify the chain¶

genesis-mesh trust delegate verify \
    --agreement agreement.json \
    --delegation delegation.json \
    --offerer-public-key <org-a-pub-b64> \
    --responder-public-key <bank-pub-b64> \
    --key org-a:<org-a-pub-b64> \
    --key agent-x:<agent-x-pub-b64>

Expected output:

[OK] accepted
Chain     : 1 hop(s)

Exit code 0.

Flow: Agent X further delegates to Agent Y (two hops)¶

After Agent X holds a valid delegation.json, it can further delegate:

# Agent X creates delegation to Agent Y (half-signed)
genesis-mesh trust delegate create \
    --parent-delegation delegation.json \
    --from agent-x \
    --to agent-y \
    --capability transactions.read \
    --valid-until 2026-11-01T00:00:00Z \
    --graph agent-x-graph.json \
    --signing-key agent-x.key --key-id agent-x-2026 \
    --output delegation2-half.json

# Agent Y cosigns
genesis-mesh trust delegate cosign \
    --delegation delegation2-half.json \
    --graph agent-y-graph.json \
    --signing-key agent-y.key --key-id agent-y-2026 \
    --output delegation2.json

# Verify the full two-hop chain
genesis-mesh trust delegate verify \
    --agreement agreement.json \
    --delegation delegation.json \
    --delegation delegation2.json \
    --offerer-public-key <org-a-pub-b64> \
    --responder-public-key <bank-pub-b64> \
    --key org-a:<org-a-pub-b64> \
    --key agent-x:<agent-x-pub-b64> \
    --key agent-y:<agent-y-pub-b64>

Expected output:

[OK] accepted
Chain     : 2 hop(s)

DelegatedAgreementRecord structure¶

DelegatedAgreementRecord
  delegation_id           — unique to this delegation
  parent_id               — agreement_id or delegation_id of the parent
  parent_kind             — "agreement" or "delegation"
  parent_terms_digest     — SHA-256 of parent's canonical agreed_terms JSON
  delegator_sovereign_id  — party passing authority
  delegate_sovereign_id   — party receiving authority
  delegated_terms
    capabilities          — subset of parent capabilities
    scope                 — operator constraints
    valid_from            — window start
    valid_until           — window end (≤ parent expires_at)
    freshness_commitment  — minimum revocation-feed sequence
  delegator_evidence      — TrustEvidence (delegator → delegate), signed
  delegate_evidence       — TrustEvidence (delegate → delegator), embedded
  graph_digest            — SHA-256 of delegator's recognition graph
  established_at          — UTC timestamp
  expires_at              — delegation validity ceiling
  signatures              — Ed25519 signatures from delegator and delegate

Failure cases¶

Widening capabilities: trust delegate create with --capability values outside the parent’s scope exits non-zero with “exceed parent scope”.

Extending validity beyond parent: trust delegate create with --valid-until > parent’s expires_at exits non-zero with “exceeds parent expires_at”.

Non-party delegator: trust delegate create with --from not in the parent record’s parties exits non-zero with “not a party in the parent record”.

Wrong key on verify: trust delegate verify exits 1 with [FAIL] invalid_delegator_signature or [FAIL] invalid_delegate_signature.

Parent terms changed: If the parent AgreementRecord terms are amended after the delegation was issued, trust delegate verify exits 1 with [FAIL] terms_digest_mismatch.

Missing hops: An empty --delegation list exits 1 with [FAIL] empty_chain.

Canonical form note¶

DelegatedAgreementRecord.to_canonical_json() excludes delegate_evidence, signatures, delegation_id, and established_at. This allows the delegator to sign first (before the delegate’s evidence exists) and the delegate to sign the same canonical form during cosign.

The delegator’s evidence IS in the canonical form — bound by the delegator’s signature and verifiable by the delegate. The delegate’s own signature is their binding claim of acceptance.

What delegation does NOT prove¶

That new treaty rights were created. Delegation evaluates existing rights at every hop. Capabilities can only narrow.
That execution is authorised. The delegation establishes who holds delegated rights, not whether a specific interaction may proceed. That is the Relationship Context layer (v0.28).
That the parent agreement is still valid. Verify the root AgreementRecord separately (trust agree verify) to confirm it has not been superseded.
