Worked Example: Freshness Proofs + Bounded Revocation¶

This example shows how a feed-serving node issues a signed FreshnessProof, how a BoundaryEngine embeds it in a BoundaryDecision, and how a verifier confirms the proof was current when the decision was made.

Scenario¶

bank-a operates a revocation feed. Before authorizing a capability request, bank-a’s BoundaryEngine requires that the requester present a valid FreshnessProof attesting that the feed’s current sequence was observed recently. The proof is embedded in the BoundaryDecision and can be verified offline.

Step 1 — Issue a FreshnessProof¶

The feed-serving node issues a signed proof for the current feed state:

genesis-mesh trust freshness issue \
    --feed-sovereign bank-a \
    --feed-sequence 42 \
    --issuer-sovereign feed-node-1 \
    --valid-for 300 \
    --signing-key keys/feed-node.key --key-id node-2026 \
    --output freshness-proof.json

Proof ID    : f1e2d3c4-...
Feed sov    : bank-a
Sequence    : 42
Attested at : 2026-06-22T14:00:00+00:00
Valid until : 2026-06-22T14:05:00+00:00
Output      : freshness-proof.json

The proof is valid for 5 minutes.

Step 2 — Evaluate with the BoundaryEngine (require_freshness_proof=True)¶

Pass the proof to the engine alongside the ContextRecord:

genesis-mesh trust context evaluate \
    --context context.json \
    --agreement agreement.json \
    --operator-sovereign bank-a \
    --signing-key keys/bank-a.key --key-id bank-a-2026 \
    --freshness-proof freshness-proof.json \
    --freshness-issuer-key <feed-node-public-key-b64> \
    --output decision.json

Decision   : 3b7e9f12-...
Authorized : true
Gate results:
  [PASS] capability_check: capability 'transactions.read' is in agreed scope
  [PASS] validity_window: request within window
  [PASS] freshness_check: freshness seq 42 >= commitment 42
  [PASS] freshness_proof: proof valid, seq=42 >= commitment=42
Output     : decision.json

Exit code 0 — all gates passed including the freshness_proof gate. The BoundaryDecision.freshness_proof field is populated.

Step 3 — Evaluate without a proof (requirement not met)¶

genesis-mesh trust context evaluate \
    --context context.json \
    --agreement agreement.json \
    --operator-sovereign bank-a \
    --signing-key keys/bank-a.key --key-id bank-a-2026 \
    --output decision-denied.json

Decision   : 8c9d0e1f-...
Authorized : false
Gate results:
  [PASS] capability_check: capability 'transactions.read' is in agreed scope
  [PASS] validity_window: request within window
  [PASS] freshness_check: freshness seq 42 >= commitment 42
  [FAIL] freshness_proof: freshness_proof required but not provided
Output     : decision-denied.json

Exit code 1.

Step 4 — Verify a FreshnessProof standalone¶

genesis-mesh trust freshness verify \
    --proof freshness-proof.json \
    --issuer-key <feed-node-public-key-b64> \
    --required-sequence 42

[OK] valid
Feed sov    : bank-a
Sequence    : 42 (required: 42)
Valid until : 2026-06-22T14:05:00+00:00

Step 5 — Detect a stale proof¶

If execution records are produced after the proof expired, chain verification flags the staleness:

genesis-mesh trust execution verify \
    --decision-id 3b7e9f12-... \
    --evidence evidence-1.json \
    --key bank-a:<bank-a-pub-b64>

If evidence-1.json.executed_at > decision.freshness_proof.proof_valid_until:

[FAIL] stale_freshness_proof
Chain     : 1 record(s)
Failed at : sequence 1

What the proof guarantees¶

Claim	Mechanism
Feed was at sequence N at time T	`attested_at` + `feed_digest` in proof
Proof is authentic	Ed25519 signature by feed-serving node
Proof was current at decision time	`proof_valid_until >= decision_made_at`
Execution occurred while proof was valid	`executed_at <= proof_valid_until`

The freshness_commitment in AgreementTerms sets the floor: any BoundaryDecision issued under that agreement must prove the feed was at or beyond that sequence. Any execution occurring after the proof window is flagged as stale_freshness_proof during chain verification.
